ONE PLY
Type 3 Flat Eye |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EE1-901PF |
1,600 |
1,250 |
3,200 |
EE1-902PF |
3,200 |
2,500 |
6,400 |
EE1-903PF |
4,800 |
3,800 |
9,600 |
EE1-904PF |
6,400 |
5,000 |
12,800 |
EE1-906PF |
9,600 |
7,700 |
19,200 |
EE1-908PF |
12,800 |
10,200 |
25,600 |
EE1-910PF |
16,000 |
12,800 |
32,000 |
EE1-912PF |
19,200 |
15,400 |
68,400 |
TWO PLY
Type 3 Flat Eye |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EE2-901PF |
3,200 |
25,900 |
6,400 |
EE2-902PF |
6,400 |
5,000 |
12,800 |
EE2-903PF |
8,600 |
6,900 |
17,200 |
EE2-904PF |
11,500 |
9,200 |
23,000 |
EE2-906PF |
16,300 |
13,000 |
32,600 |
EE2-908PF |
19,200 |
15,400 |
38,400 |
EE2-910PF |
22,400 |
17,900 |
44,800 |
EE2-912PF |
26,900 |
21,500 |
53,800 |
THREE PLY
Type 3 Flat Eye |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EE3-901PF |
4,100 |
3,300 |
8,200 |
EE3-902PF |
8,300 |
6,600 |
16,600 |
EE3-903PF |
12,500 |
10,000 |
25,000 |
EE3-904PF |
16,000 |
12,800 |
32,000 |
EE3-906PF |
26,000 |
18,400 |
46,000 |
EE3-908PF |
30,700 |
24,500 |
61,400 |
EE3-910PF |
36,800 |
29,400 |
73,600 |
EE3-912PF |
44,000 |
35,200 |
88,000 |
FOUR PLY
Type 3 Flat Eye |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EE4-901PF |
5,000 |
4,000 |
10,000 |
EE4-902PF |
10,000 |
8,000 |
20,000 |
EE4-903PF |
14,900 |
11,900 |
29,800 |
EE4-904PF |
19,800 |
15,800 |
39,600 |
EE4-906PF |
22,800 |
23,800 |
59,600 |
EE4-908PF |
39,700 |
31,700 |
79,400 |
EE4-910PF |
49,600 |
39,600 |
99,200 |
EE4-912PF |
59,500 |
47,600 |
119,000 |
One Ply
Type 5 Endless |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EN1-901PF |
3,200 |
2,500 |
6,400 |
EN1-902PF |
6,400 |
5,000 |
12,800 |
EN1-903PF |
8,600 |
6,900 |
17,200 |
EN1-904PF |
11,500 |
9,200 |
23,000 |
EN1-906PF |
16,300 |
13,000 |
32,600 |
EN1-908PF |
19,200 |
15,400 |
38,400 |
EN1-910PF |
22,400 |
17,900 |
44,800 |
EN1-912PF |
26,900 |
21,500 |
53,800 |
Two Ply
Type 5 Endless |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EN2-901PF |
6,200 |
4,900 |
12,400 |
EN2-902PF |
12,200 |
9,800 |
24,400 |
EN2-903PF |
16,300 |
13,000 |
32,600 |
EN2-904PF |
20,700 |
16,500 |
41,400 |
EN2-906PF |
28,600 |
23,000 |
57,200 |
EN2-908PF |
30,700 |
24,500 |
61,400 |
EN2-910PF |
33,600 |
26,800 |
67,200 |
EN2-912PF |
37,600 |
30,000 |
75,200 |
Three Ply
Type 5 Endless |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EN3-901PF |
8,000 |
6,400 |
16,000 |
EN3-902PF |
16,000 |
12,800 |
32,000 |
EN3-903PF |
21,500 |
17,200 |
43,000 |
EN3-904PF |
28,700 |
23,000 |
57,400 |
EN3-906PF |
40,700 |
32,500 |
81,400 |
EN3-908PF |
46,000 |
36,800 |
92,000 |
EN3-910PF |
51,500 |
41,200 |
103,000 |
EN3-912PF |
59,200 |
47,300 |
118,400 |
Four Ply
Type 5 Endless |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EN4-901PF |
10,000 |
8,000 |
20,000 |
EN4-902PF |
19,800 |
15,800 |
39,600 |
EN4-903PF |
26,700 |
21,300 |
53,400 |
EN4-904PF |
35,600 |
28,400 |
71,200 |
EN4-906PF |
50,500 |
40,400 |
101,000 |
EN4-908PF |
57,600 |
46,000 |
115,200 |
EN4-910PF |
67,200 |
53,700 |
134,400 |
EN4-912PF |
80,700 |
64,500 |
161,400 |
One Ply
Type 1 Triangle Choker |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
TC1-902P |
3,200 |
2,500 |
6,400 |
TC1-903P |
4,800 |
3,800 |
9,600 |
TC1-904P |
6,400 |
5,000 |
12,800 |
TC1-906P |
9,600 |
7,700 |
19,200 |
TC1-908P |
12,800 |
10,200 |
25,600 |
TC1-910P |
16,000 |
12,800 |
32,000 |
TC1-912P |
19,200 |
15,400 |
68,400 |
Two Ply
Type I Triangle Choker |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
TC2-902P |
6,400 |
5,000 |
12,800 |
TC2-903P |
8,600 |
6,900 |
17,200 |
TC2-904P |
11,500 |
9,200 |
23,000 |
TC2-906P |
16,300 |
13,000 |
32,600 |
TC2-908P |
19,200 |
15,400 |
38,400 |
TC2-910P |
22,400 |
17,900 |
44,800 |
TC2-912P |
26,900 |
21,500 |
53,800 |
Three and four ply hardware slings are available upon request.
**Type 2 cannot be used in a choker hitch.
ONE PLY
Type 3 Flat Eye |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EE1-901PF |
1,600 |
1,250 |
3,200 |
EE1-902PF |
3,200 |
2,500 |
6,400 |
EE1-903PF |
4,800 |
3,800 |
9,600 |
EE1-904PF |
6,400 |
5,000 |
12,800 |
EE1-906PF |
9,600 |
7,700 |
19,200 |
EE1-908PF |
12,800 |
10,200 |
25,600 |
EE1-910PF |
16,000 |
12,800 |
32,000 |
EE1-912PF |
19,200 |
15,400 |
68,400 |
TWO PLY
Type 3 Flat Eye |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EE2-901PF |
3,200 |
25,900 |
6,400 |
EE2-902PF |
6,400 |
5,000 |
12,800 |
EE2-903PF |
8,600 |
6,900 |
17,200 |
EE2-904PF |
11,500 |
9,200 |
23,000 |
EE2-906PF |
16,300 |
13,000 |
32,600 |
EE2-908PF |
19,200 |
15,400 |
38,400 |
EE2-910PF |
22,400 |
17,900 |
44,800 |
EE2-912PF |
26,900 |
21,500 |
53,800 |
THREE PLY
Type 3 Flat Eye |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EE3-901PF |
4,100 |
3,300 |
8,200 |
EE3-902PF |
8,300 |
6,600 |
16,600 |
EE3-903PF |
12,500 |
10,000 |
25,000 |
EE3-904PF |
16,000 |
12,800 |
32,000 |
EE3-906PF |
26,000 |
18,400 |
46,000 |
EE3-908PF |
30,700 |
24,500 |
61,400 |
EE3-910PF |
36,800 |
29,400 |
73,600 |
EE3-912PF |
44,000 |
35,200 |
88,000 |
FOUR PLY
Type 3 Flat Eye |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EE4-901PF |
5,000 |
4,000 |
10,000 |
EE4-902PF |
10,000 |
8,000 |
20,000 |
EE4-903PF |
14,900 |
11,900 |
29,800 |
EE4-904PF |
19,800 |
15,800 |
39,600 |
EE4-906PF |
22,800 |
23,800 |
59,600 |
EE4-908PF |
39,700 |
31,700 |
79,400 |
EE4-910PF |
49,600 |
39,600 |
99,200 |
EE4-912PF |
59,500 |
47,600 |
119,000 |
One Ply
Type 5 Endless |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EN1-901PF |
3,200 |
2,500 |
6,400 |
EN1-902PF |
6,400 |
5,000 |
12,800 |
EN1-903PF |
8,600 |
6,900 |
17,200 |
EN1-904PF |
11,500 |
9,200 |
23,000 |
EN1-906PF |
16,300 |
13,000 |
32,600 |
EN1-908PF |
19,200 |
15,400 |
38,400 |
EN1-910PF |
22,400 |
17,900 |
44,800 |
EN1-912PF |
26,900 |
21,500 |
53,800 |
Two Ply
Type 5 Endless |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EN2-901PF |
6,200 |
4,900 |
12,400 |
EN2-902PF |
12,200 |
9,800 |
24,400 |
EN2-903PF |
16,300 |
13,000 |
32,600 |
EN2-904PF |
20,700 |
16,500 |
41,400 |
EN2-906PF |
28,600 |
23,000 |
57,200 |
EN2-908PF |
30,700 |
24,500 |
61,400 |
EN2-910PF |
33,600 |
26,800 |
67,200 |
EN2-912PF |
37,600 |
30,000 |
75,200 |
Three Ply
Type 5 Endless |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EN3-901PF |
8,000 |
6,400 |
16,000 |
EN3-902PF |
16,000 |
12,800 |
32,000 |
EN3-903PF |
21,500 |
17,200 |
43,000 |
EN3-904PF |
28,700 |
23,000 |
57,400 |
EN3-906PF |
40,700 |
32,500 |
81,400 |
EN3-908PF |
46,000 |
36,800 |
92,000 |
EN3-910PF |
51,500 |
41,200 |
103,000 |
EN3-912PF |
59,200 |
47,300 |
118,400 |
Four Ply
Type 5 Endless |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
EN4-901PF |
10,000 |
8,000 |
20,000 |
EN4-902PF |
19,800 |
15,800 |
39,600 |
EN4-903PF |
26,700 |
21,300 |
53,400 |
EN4-904PF |
35,600 |
28,400 |
71,200 |
EN4-906PF |
50,500 |
40,400 |
101,000 |
EN4-908PF |
57,600 |
46,000 |
115,200 |
EN4-910PF |
67,200 |
53,700 |
134,400 |
EN4-912PF |
80,700 |
64,500 |
161,400 |
One Ply
Type 1 Triangle Choker |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
TC1-902P |
3,200 |
2,500 |
6,400 |
TC1-903P |
4,800 |
3,800 |
9,600 |
TC1-904P |
6,400 |
5,000 |
12,800 |
TC1-906P |
9,600 |
7,700 |
19,200 |
TC1-908P |
12,800 |
10,200 |
25,600 |
TC1-910P |
16,000 |
12,800 |
32,000 |
TC1-912P |
19,200 |
15,400 |
68,400 |
Two Ply
Type I Triangle Choker |
Vertical (lbs.) |
Choker (lbs.) |
Basket (lbs.) |
|---|---|---|---|
TC2-902P |
6,400 |
5,000 |
12,800 |
TC2-903P |
8,600 |
6,900 |
17,200 |
TC2-904P |
11,500 |
9,200 |
23,000 |
TC2-906P |
16,300 |
13,000 |
32,600 |
TC2-908P |
19,200 |
15,400 |
38,400 |
TC2-910P |
22,400 |
17,900 |
44,800 |
TC2-912P |
26,900 |
21,500 |
53,800 |
Three and four ply hardware slings are available upon request.
**Type 2 cannot be used in a choker hitch.
Note:
HARDWARE – Aluminum hardware is standard on single ply TYPES 1 & 2 slings in 2″, 3″, 4″ and 6″ widths:
TAPERING – Types 3 and 4 are tapered at 3″ and wider unless otherwise ordered.
These wider slings are tapered at the bearing points to accommodate a crane hook.
CAUTION- DO NOT EXCEED RATED CAPACITIES!
